📄 You can view the PDF above or download it here.

Article Code	Features
S-JUNO-LOEU-ID	JUNO IP69k temperature, tilt detection and opening detection LoRaWAN
S-JUNO-MIOTY-ID	JUNO IP69k temperature, tilt detection and opening detection mioty
S-JUNO-IX-LOEU-ID	INDUSTRIAL JUNO IP69k temperature, tilt detection and opening detection LoRaWAN
S-JUNO-IX-MIOTY-ID	INDUSTRIAL JUNO IP69k temperature, tilt detection and opening detection mioty

Feature	Value	Unit
Dimensions lxbxh	86x86x25	mm
Weight	<200	g
Operating temperature	-25 to +75 (extended temperature range on request. Temperature range is limited by the maximum operating temperature of the primary cells)	°C
Maximum operating temperature Device	85	°C
Storage temperature (recommended)	15 to +30	°C
Rel. humidity during operation	5 to 99	%RH
IP Rating	IP69k
IK Rating	TBD
Sensors	Temperature, relative humidity, acceleration sensor
Traffic light function	no
Audible alarm function	Yes, buzzer
Provisioning	NFC
Material	PBT GF20 + ASA
NFC antenna	Integrated
RF antenna	Integrated
Accelerometer	Yes
Batteries	Primary cell, replaceable, AA
Primary cell type	LoRaWAN, mioty: • 2 x 3.6V LiSOCl2 (recommended SAFT LS14500)
Housing color	S-JUNO-XXXX black S-JUNO-IX-XXXX silk grey

Feature	Value	Unit
RF Standards		MHz
Frequency LoRaWAN®/mioty® EU	868	MHz
Transmission power LoRaWAN®/mioty® EU	14	dBm
LoRa® MAC layer version	1.0.4

Feature	Value	Unit
Measuring range	0 to 360	°
Accuracy	+/-2°	°
Triggering in low power mode for opening detection	+/-60	°

Feature	Value	Unit
Measuring range	-40 to +85	°C
Accuracy	+/- 0.8	°C

Specifications subject to change without notice. All information provided without guarantee.

Juno ID Tilt Technical data sheet

Are you looking for Juno ID TILT technical data sheet?
