Apollon-Q-T/R/TR Dataconverter
Are you looking for the Apollon-Q T/R/TR Payload description?
Here you can find the payload description for the Apollon-Q T/R/TR
Apollon-Q-T/R/TR Payload Decoder LoRaWAN®
// Up to Date Apollon decoder
function Decoder(bytes, port) {
// Conversion of signed integers
function uncomplement(val, bitwidth) {
var isnegative = val & (1 << (bitwidth - 1));
var boundary = (1 << bitwidth);
var minval = -boundary;
var mask = boundary - 1;
return isnegative ? minval + (val & mask) : val;
}
var decoded = {};
if (port === 1) {
// Attributes
decoded.base_id = bytes[0] >> 4;
decoded.major_version = bytes[0] & 0x0F;
decoded.minor_version = bytes[1] >> 4;
decoded.product_version = bytes[1] & 0x0F;
// Telemetry
decoded.up_cnt = bytes[2];
decoded.battery_voltage = ((bytes[3] << 8) | bytes[4]) / 1000.0;
decoded.internal_temperature = bytes[5] - 128;
decoded.alarm = bytes[6] ? "ALARM" : "NO ALARM";
decoded.master_value = ((bytes[7] << 8) | bytes[8]); // in mm
// Start of version specific fields
var byte_cnt = 9;
// ToF onboard
if (bytes[1] & 0x01) {
decoded.tof_status = bytes[byte_cnt++];
decoded.tof_distance = ((bytes[byte_cnt++] << 8) | bytes[byte_cnt++]); // in mm
decoded.tof_index = bytes[byte_cnt++];
}
// Radar onboard
if (bytes[1] & 0x02) {
decoded.radar_status = bytes[byte_cnt++];
decoded.radar_no_peaks = bytes[byte_cnt++];
decoded.radar_distance_1 = ((bytes[byte_cnt++] << 8) | bytes[byte_cnt++]);
decoded.radar_amplitude_1 = uncomplement((bytes[byte_cnt++] << 8) | bytes[byte_cnt++], 16);
decoded.radar_distance_2 = ((bytes[byte_cnt++] << 8) | bytes[byte_cnt++]);
decoded.radar_amplitude_2 = uncomplement((bytes[byte_cnt++] << 8) | bytes[byte_cnt++], 16);
decoded.radar_distance_3 = ((bytes[byte_cnt++] << 8) | bytes[byte_cnt++]);
decoded.radar_amplitude_3 = uncomplement((bytes[byte_cnt++] << 8) | bytes[byte_cnt++], 16);
}
// ACC onboard
if (bytes[1] & 0x04) {
decoded.acc_status = bytes[byte_cnt++] ? "Fehler" : "OK";
decoded.acc_orientation = bytes[byte_cnt++];
decoded.acc_open = bytes[byte_cnt++];
decoded.acc_open_cnt = ((bytes[byte_cnt++] << 8) | bytes[byte_cnt++]);
decoded.acc_impact = bytes[byte_cnt++] ? "Vandalismus" : "OK";
}
// Hall onboard
if (bytes[1] & 0x08) {
decoded.hall_open = bytes[byte_cnt++];
decoded.hall_open_cnt = ((bytes[byte_cnt++] << 8) | bytes[byte_cnt++]);
}
}
return decoded;
}
