Juno ID TILT General description

Are you looking for a general description for the Juno ID TILT?

📄 You can view the PDF above or download it here.

The JUNO ID/TILT is designed for reliable detection of tilt angles and the opening of flaps, covers, or doors. It features a high-precision accelerometer and an integrated magnetic switch for accurate event detection. The “ID” refers to passive tracking via LoRaWAN®or Mioty where the device can be located based on the receiving gateway. Configuration is possible via NFC or downlinks. With its compact, IP69k-rated housing, it withstands dust, water, and high-pressure cleaning — ideal for demanding environments.

🛠️ Features

LoRaWAN®, mioty®, LTE-CAT-M1 or NB-IoT communication
IP69k, -25 °C to 85 °C, IK07
Tilt and flap opening detection
Advanced tilt detection with 1° resolution and limit values
Magnetic switch for contact or flap state detection
Can be activated with a magnet (no smartphone required) or via NFC
Configurable via downlinks or NFC
Adjustable limit values
Replaceable AA cells (LiSOCl₂, e.g., Saft LS14500)
Acoustic signal

📦 Example Applications

Cold chain monitoring
Temperature monitoring in building management or smart city applications
Manhole cover monitoring
Flap opening detection

Versions

Article Code	Features
S-JUNO-LOEU	JUNO IP69k sensor with tilt and flap opening detection, LoRaWAN®
S-JUNO-MIOTY	JUNO IP69k sensor with tilt and flap opening detection, mioty
S-JUNO-NB	JUNO IP69k sensor with tilt and flap opening detection, NB-IoT
S-JUNO-IX-LOEU	INDUSTRIAL JUNO IP69k sensor with tilt and flap opening detection, LoRaWAN
S-JUNO-IX-MIOTY	INDUSTRIAL JUNO IP69k sensor with tilt and flap opening detection, mioty
S-JUNO-IX-NB	INDUSTRIAL JUNO IP69k sensor with tilt and flap opening detection, NB-IoT

Specifications subject to change without notice. All information provided without guarantee.
